| NO. |
item |
Parameter |
| 1 |
operating weight |
8200kg |
| 2 |
dimension |
6150*2250*3630mm |
| 3 |
wheel base |
2264mm |
| 4 |
Min Ground Clearance |
300mm |
| 5 |
bucket capacity |
1.0 cbm |
| 6 |
breakout force |
38KN |
| 7 |
loading lifting capacity |
2500kg |
| 8 |
dump height |
2650mm |
| 9 |
dump reach |
1025mm |
| 10 |
loading cutting depth |
52mm |
| 11 |
backhoe capacity |
0.3 cbm |
| 12 |
Max. digging depth |
4082mm |
| 13 |
digging slewing angel |
190 |
| 14 |
Max. pulling force |
39kn |
|
ENGINE: |
|
| 15 |
Model |
DEUTZ WP4G95E221 |
| 16 |
Type |
inline, direct injection, water cool, turbochared, 4- stroke. |
| 17 |
cylinder-inner diameter*stroke |
4-105*130 |
| 18 |
rated power |
70kw |
| 19 |
rated speed |
2200/r/min |
| 20 |
Min fuel consumption |
less 230g/km/h |
| 21 |
Maz torqure |
380 N.m / 1400-1600 rpm |
| 22 |
displacement |
4.5L |
|
STEERING SYSTEM |
|
| 23 |
diverter model |
BZZ5-250 |
| 24 |
Steering angle |
36 |
| 25 |
min turning radius |
6581mm |
| 26 |
System pressure |
12MPa |
|
AXLE |
|
| 27 |
manufacturer |
Italy Carraro |
| 28 |
Total time |
10.95smore/less0.5s |
| 29 |
rated dynamic/static load of front axle |
9T/22.5T |
| 30 |
rated dynamic / static load of rear axle |
7.5/18.75T |
|
TRANSMISSION-GEARBOX: |
|
| 31 |
model |
TLB1-4WD |
| 32 |
type |
fixed shaft powershift electric control |
| 32 |
TYRE |
|
| 33 |
front/rear model |
12-16.5-12 / 19.5L-24-12prr-4 |
| 34 |
front tire pressure |
0.55Mpa |
| 35 |
Rear tire pressure |
0.23Mpa |
|
BRAKE SYSTEM |
|
| 35 |
Rear tire pressure |
0.23Mpa |
| 36 |
service brake |
wet internal, self-regulation , self-balance |
| 37 |
parking/emergency brake |
spring brake/hydrualic terminating brake. |
| 38 |
travel speed |
38km/h |
|
HYDRAULIC SYSTEM |
|
| 39 |
bucket digging power |
46.5kn |
| 40 |
digging power of dipper |
31kn |
| 41 |
total cycling time |
11.9 ± 0.15 s |
